Machine used for rewinding pallet stretch of 17-23 micron thickness from jumbo rolls to rolls of 10-1500 meters long. Machine rewinding speed could reach to 1400 m/min with the 2 servo motors and jumbo roll could be right-left adjustable.
Machine Speed
1400 m/min
Idle Roller Width
600mm
Electric Power
2x5 Kw
Core Size
Ø 38 - Ø 50 - Ø 76 mm
ASR1200-XLS
Technical Specifications
ASR1200-XLS Automatic Stretch Wrapping Machine
- Machine Speed: 1400 m/min
- Rewinding Time: 19 Sec (300m) - 80 Sec (1500m)
- Idle Roller Width (Max): 600mm
- Core Size: Ø 38 - Ø 50 - Ø 76 mm
- Main Motor: 2x5 Kw Servo Motor
- Rewinding Diameter (Max): 300mm
- Jumbo Coil Weight (Max): 75 Kg
ASR1200-XLS
Machine Specifications
ASR1200-XLS Fully Automatic Machine Detailed Features
- Full Automatic Rewinding And Changing
- Unit Counter And Quantity Reporting
- Film Finish Sensor
- Coil Finish Sensor
- Cutting With Hot Wire
- Omron Plc Control System
ASR1200-XLS
General Specifications
General Feature Information For Our ASR1200-XLS Machine
- OMRON 7" Touch Panel
- Omron Main Driver
- Mindman Pneomatic System
- Paper Core Magazine (50Pcs - 76mm)
- Machine Weight: 1200 Kg
- Machine Dimensions: 1550x1500x1850 mm
